CONVENTIONAL EXCAVATORS

Don’t let their name fool you. KOBELCO conventional excavators are anything but. With high-quality construction and low-cost maintenance, they’re as cost-effective as they are dependable.

SK260LC-11

  • Engine Power - 178 hp (133 kW)
  • Operating Weight - 60,200 lbs (27,300 kg)

The SK260LC-11 is one of the new KOBELCO excavators engineered to bring together superior performance and design. This new Generation -11 machine is equipped with a Yanmar Tier IV Final compliant engine with 194 hp, which has a higher torque value increasing performance. The KOBELCO SK260LC-11 is more durable than ever and able to withstand the rigors of the toughest job sites. The revolutionary technology provides a 10-inch high resolution screen the operator can customize to provide all the input they need for the job.

The SK260LC-11 has many exclusive operator comforts like a heated air ride suspension seat, multi vent air conditioner, ergonomic adjustable lever angles and joystick, interior LED lights and a tilting left console for easy entry and exit. All to promote productivity and operator safety.


Watch the Video:

SK260LC-11 Excavator Walkthrough

Construction Equipment 2022 Top New Products Logo

Overall Height (to top of boom)10' 11" (3,320 mm)
Overall Width11' 1" (3,390 mm)
Ground Clearance of Rear End3' 7" (1,090 mm)
Ground Clearance17.3" (440 mm)
Tail Swing Radius10' 2" (3,100 mm)
Distance From Center of Swing To Rear End10' 1" (3,070 mm)
Tumbler Distance12' 8" (3,850 mm)
Track Gauge8' 6" (2,590 mm)
Shoe Width31.5 (800 mm)
Overall Width of Upperstructure10' 3" (3,120 mm)

PERFORMANCE

Travel Speed3.6 mph (5.8 kph) / 2.2 mph (3.6 kph)
Drawbar Pulling Force54,600 lbf (243 kN)

WEIGHT

Operating Weight60,200 lbs (27,300 kg)

ENGINE

ModelYanmar 4TNV107FTT
Power Output 208 hp (155 kW)
194 hp (145 kW)
Max. Torque594 lbf (805 Nm)
Displacement278.7 in³ (4.57 ltr)
Fuel Tank106.5 gallons (US) (403 ltr)

HYDRAULIC SYSTEM

Number of Main Pumps 2
Max. Digging Reach33' 10" (10,300 mm)
Max. Digging Reach At Ground Level33' 3" (10,140 mm)
Max. Digging Depth23' (7,000 mm)
Max. Digging Height32' 1" (9,790 mm)
Max. Dumping Clearance22' 7" (6,880 mm)
Max. Vertical Wall Digging Depth20' 2" (6,150 mm)
Min. Swing Radius12' 10" (3,910 mm)
Digging Depth For 8 Feet Flat Bottom22' 4" (6,820 mm)
Bucket Digging Force42,000 lbf (187 kN)
Arm Crowding Force30,100 lbf (134 kN)
